分支電纜
- 包含：普通型、阻燃型（ZR）、耐火型(NH)
預分支電纜主要有主干電纜、分支線、分支接頭、相關附件組成，并具有三種類型：普通型、阻燃型（ZR）、耐火型(NH)。
預分支電纜是高層建筑中母線槽供電的替代產品，具有供電可靠、安裝方便、防水性好，占建筑面積小、故障率低、價格便宜、免維修維護等。
預分支電纜是為配合城市高層建筑供電系統而開發的成套產品，主要用于高層建筑。
產品型號及名稱 TYPE & TITLE
| 型號Type | 名稱Title | |||||
| FZ-YJV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套預制分支電纜 Cu conductor XLPE insulated PVC sheathed prefabricated branch cable | |||||
| Z-FZ-YJV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套阻燃預制分支電纜 Cu conductor XLPE insulated PVC sheathed flame-resistant prefabricated branch cable | |||||
| WDZ-FZ-YJV | 銅芯交聯聚乙烯絕緣無鹵低煙聚烯烴護套阻燃預制分支電纜 Cu condutor XLPE insulated low smoke halogen free PE sheathed flame-resistant prefabricated branch cable | |||||
| FZ-VV | 銅芯聚氯乙烯絕緣聚氯乙烯護套預制分支電纜 Cu core PVC insulated PVC sheathed prefabricated branch cable | |||||
| Z-FZ-VV | 銅芯聚氯乙烯絕緣聚氯乙烯護套阻燃預制分支電纜 Cu core PVC insulated PVC sheathed flame-resistant-prefabricated branch cable | |||||
| N-FZ-YJV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套耐火預制分支電纜 Cu core XLPE insulated PVC sheathed PVC sheathed fire-resistant prefabricated branch cable | |||||
主要技術參數Main Technical Parameter
主干電纜標稱截面 main cable cross section(mm2) | 分支電纜標稱截面 Branch Cable Cross-section (mm2) | ||||||||
| 35 | 10 | 16 | 25 | - | - | - | - | - | - |
| 50 | 10 | 16 | 25 | 35 | - | - | - | - | - |
| 70 | 10 | 16 | 25 | 35 | - | - | - | - | - |
| 95 | 10 | 16 | 25 | 35 | 50 | - | - | - | - |
| 120 | 10 | 16 | 25 | 35 | 50 | 70 | - | - | - |
| 150 | 10 | 16 | 25 | 35 | 50 | 70 | - | - | - |
| 185 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | - | - |
| 240 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | - |
| 300 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 |
| 400 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 |
| 500 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 |
| 630 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 |
訂貨須知 Ordering Information
為了更好的設計您的預制分支電纜，請用戶提供以下資料：
In order to better design your prefabricated branch cable, please provide the following information：
【建筑物類別】：高層建筑，體育場館、公路等。
Building Category:high buildings,stadiums,roads.etc.
【建筑物構造】：建筑物配電系統圖，預制帶分支電纜的布置。
Building Construction：building power distribution system maps,prefabricated branch cable layout.
【配電方式】：?jiǎn)蜗嚯p線、單相三線、三相三線、三相四線、三相五線制。
Distribution method:single-phase two –wire,single-phase three-wire,three-phase three-wire,three-phase four-wire,three-phase five-wire.
【預制帶分支電纜】：電纜型號、主干及分支電纜的截面、各分支連接盒間距離、主干電纜長度，分支電纜長度等。
Prefabricated branch cable:cable type,the section of main and branch cables,the distance between the branch junction box,length of main cable,length of branch cable.
【敷設方式】：由樓頂上拉下或從地面拉上樓頂。
Installation method:pull down from the roof to ground or pull up from the ground to roof.
【 上端支撐】：用或不用電纜懸吊裝置、電纜夾緊裝置。
Support of top: with or without cable suspension device,cable clamping device.
【 附件】：夾具、托架等。Accessories clamps,brackets,etc.
【電纜盤具】Cable tray.
【其他要求】Other requirements.
